Nanya Announces $10.7B Investment in Fab5A, Aims for 10 nm-Class EUV DRAM

Nanya Technology Board of Directors announced on August 5 that the company has launched its largest investment program, committing up to NT$346.6 billion (around $10.7 billion) to its Fab5A facility through 2026-2029. The project covers 10 nm-class processes from 1b through 1e nodes and introduces EUV lithography. Nanya has also increased its 2026 capital expenditures budget by 34% to NT$69.7 billion (around $2.16 billion). The extra NT$17.7 billion is going toward advance payments for equipment to keep Fab5A on schedule. The production roadmap has wafer starts being produced in the second half of 2027, reaching 30,000 wafers per month in 2028 and 35,900 in 2029. The maximum planned capacity is around 45,000 wafers monthly. The 1c pilot production has already begun, while the 1d node is under development and expected to enter pilot production soon. Nanya Fab5A investment, when completed, is estimated at roughly $16 billion, deployed in phases based on market demand.

Commercially, Nanya is having a strong run. July revenue hit NT$43.87 billion (around $1.3 billion), up 49.3% month over month and 719.6% year over year, driven by continued DRAM price increases, particularly sharp gains in DDR4 contract prices. Remember that just a year ago DDR4 module prices overtook DDR5 for the first time, with Nanya among the biggest beneficiaries. Its customers include giants like NVIDIA, Google, Microsoft, Intel, AMD, and Qualcomm, with the future looking great for the Taiwanese company. Its long-term agreements reportedly now cover about 50% of production capacity, with short-term contracts gradually converted into long-term agreements.
